7-Spool Hydraulic Valve | SD5 Model | Factory Direct & Customizable

Kontrollmetod:Manuell

Spole:7 ventilsektioner

Nominellt flöde:45 l/min (11,8 US gpm)

Maximalt tryck:315 bar (4600 psi)

Inloppsport:G3/8

Utloppsport:G3/8

Portstorlek:G3/8

Märke:BXHS

Produkttyp:Monoblockriktningsventil

Produktserie:SD5-serien Monoblockriktningsventil

Förpackningsstorlek:23*36*13

Bruttovikt:15.30 kg

Tillgänglighet: I lager

1395 Vyer letar efter den här produkten

7-Spool Hydraulic Valve | SD5 Model | Factory Direct & Customizable

7-Spool Hydraulic Valve | SD5 Model | Factory Direct & Customizable

7-Spool Hydraulic Valve | SD5 Model | Factory Direct & Customizable drawing image

The SD5 Series 7-Spool Hydraulic Multiplier Valve is a high-performance, monoblock valve designed for a wide range of applications in construction, material handling, agriculture, and industrial vehicles. With its 7 spools and rated flow of 40 L/min, it provides precise control and efficient operation.

SD5-serien Monoblockriktningsventil Parametrar
Kontrollmetod Manuell, Pneumatisk, Elektropneumatisk, Elektrohydraulisk, Solenoid, Hydraulisk, Hydraulisk och Manuell, Kabel, Joystick
Spole 1 ventilsektion, 2 ventilsektioner, 3 ventilsektioner, 4 ventilsektioner, 5 ventilsektioner, 6 ventilsektioner, 7 ventilsektioner
Omgivningstemperaturintervall -40°C till +60°C (-40°F till +140°F)
Strukturtyp Monoblockventil
Sektion 1 sektion, 2 sektioner, 3 sektioner, 4 sektioner, 5 sektioner, 6 sektioner, 7 sektioner
Driftsviskositetsintervall 15 - 75 mm²/s (15 cSt till 75 cSt)
Nominellt flöde 40 l/min (10,5 US gpm)
Maximalt tryck 305 bar (4400 psi)
Inloppsport G3/8, G1/2, M18×1.5, M20×1.5, SAE 6, SAE 8, G1-1/2
Utloppsport G3/8, G1/2, M18×1.5, M20×1.5, SAE 6, SAE 8
Portstorlek G3/8, G1/2, M18×1.5, M20×1.5, SAE 6, SAE 8

This 7-Spool Hydraulic Multiplier Valve is built with a robust monoblock construction, providing exceptional durability and reliability. It features a rated flow of 40 L/min, a maximum pressure rating of 305 bar (4400 psi), and a wide operating viscosity range of 15 - 75 mm²/s (15 cSt to 75 cSt). Designed for demanding environments, it operates within an ambient temperature range of -40°C to +60°C (-40°F to +140°F). With its manual control and 7 spools, this valve offers precise control for a variety of hydraulic functions. This Hydraulic Multiplier Valve is ideal for applications such as telehandlers, forklifts, stackers, aerial platforms, mini-excavators, compact wheel loaders, harvesters, bale wrappers, seeding machines, and wood splitters.
