Customizable Solenoid Directional Valve | Made to Your Specifications

Kontrollmetod:Solenoid

Spole:9 ventilsektioner

Nominellt flöde:60 l/min (15,8 US gpm)

Maximalt tryck:315 bar (4600 psi)

Inloppsport:G1/2

Utloppsport:G1/2

Portstorlek:G1/2

Märke:BXHS

Produkttyp:Sektionsstyrvventil

Produktserie:DCV58-serien Sektionsstyrvventil

Förpackningsstorlek:55*28*17

Bruttovikt:33.00 kg

Tillgänglighet: I lager

1064 Vyer letar efter den här produkten

Customizable Solenoid Directional Valve | Made to Your Specifications

Customizable Solenoid Directional Valve | Made to Your Specifications

Customizable Solenoid Directional Valve | Made to Your Specifications drawing image

This is a high-performance, customizable hydraulic motor valve designed for demanding industrial applications. It features a 9-section, solenoid-controlled design, high flow rate (60 L/min), and high pressure rating (350 bar). Ideal for material handling, construction, agriculture, and industrial vehicles.

DCV58-serien Sektionsstyrvventil Parametrar
Kontrollmetod Solenoid, Solenoid och manuell
Spole 1 ventilsektion, 2 ventilsektioner, 3 ventilsektioner, 4 ventilsektioner, 5 ventilsektioner, 6 ventilsektioner, 7 ventilsektioner, 8 ventilsektioner, 9 ventilsektioner, 10 ventilsektioner, 11 ventilsektioner, 12 ventilsektioner
Omgivningstemperaturintervall -40°C till +80°C (-40°F till +176°F)
Strukturtyp Sektionsventil
Sektion 1 sektion, 2 sektioner, 3 sektioner, 4 sektioner, 5 sektioner, 6 sektioner, 7 sektioner, 8 sektioner, 9 sektioner, 10 sektioner, 11 sektioner, 12 sektioner
Driftsviskositetsintervall 15 - 75 mm²/s (15 cSt till 75 cSt)
Nominellt flöde 40 l/min (10,5 US gpm)
Maximalt tryck 350 bar (5100 psi)
Inloppsport G1/2, M22×1.5, SAE 10, 1/2 NPT
Utloppsport G1/2, M22×1.5, SAE 10, 1/2 NPT
Portstorlek G1/2, M22×1.5, SAE 10, 1/2 NPT

This versatile **hydraulic motor valve** is a **customizable, high-performance** solution for your industrial needs. The **9-section, solenoid-controlled** design provides precise and reliable operation in a wide range of applications. With a **rated flow of 60 L/min** and a **maximum pressure of 350 bar**, this valve is capable of handling demanding workloads. The **sectional valve** construction allows for easy maintenance and repair. Designed for **heavy-duty operation**, it operates within a broad temperature range (-40°C to +80°C). Suitable for use in **material handling**, **construction and earth moving**, **agriculture**, and **industrial vehicles** such as **telehandlers**, **forklifts**, **all terrain cranes**, **stackers**, **aerial platforms**, **motor graders**, **midi-excavators**, **mini-excavators**, **skid steer loaders**, and **compact wheel loaders**. Part of the **DCV58 Series**, this valve is built to meet the highest industry standards.
