Monoblock Valve P40-OW: Superior Quality and Exceptional Value

Kontrollmetod:Manuell

Spole:1 ventilsektion

Nominellt flöde:40 l/min (10,5 US gpm)

Maximalt tryck:250 bar (3600 psi)

Inloppsport:G1/2

Utloppsport:G1/2

Portstorlek:G3/8

Märke:BXHS

Produkttyp:Monoblockriktningsventil

Produktserie:P40-serien Monoblockriktningsventil

Förpackningsstorlek:23*16*11

Bruttovikt:3.00 kg

Tillgänglighet: I lager

1148 Vyer letar efter den här produkten

Monoblock Valve P40-OW: Superior Quality and Exceptional Value

Monoblock Valve P40-OW: Superior Quality and Exceptional Value

Monoblock Valve P40-OW: Superior Quality and Exceptional Value drawing image

The P40-OW Hydraulic Cut Off Solenoid Valve is a high-quality, reliable valve designed for a wide range of applications, including material handling, construction, and agriculture. It features a monoblock design, rated flow of 40 L/min, and a maximum pressure of 250 bar.

P40-serien Monoblockriktningsventil Parametrar
Kontrollmetod Manuell, Pneumatisk, Elektropneumatisk, Elektrohydraulisk, Solenoid, Hydraulisk, Hydraulisk och Manuell, Kabel, Joystick, Solenoid och Joystick, Manuell och Joystick, Magnetventil och kabel
Spole 1 ventilsektion, 2 ventilsektioner, 3 ventilsektioner, 4 ventilsektioner, 5 ventilsektioner, 6 ventilsektioner, 7 ventilsektioner
Omgivningstemperaturintervall -40°C till +80°C (-40°F till +176°F)
Strukturtyp Monoblockventil
Sektion 1 sektion, 2 sektioner, 3 sektioner, 4 sektioner, 5 sektioner, 6 sektioner, 7 sektioner
Driftsviskositetsintervall 15 - 75 mm²/s (15 cSt till 75 cSt)
Nominellt flöde 40 l/min (10,5 US gpm)
Maximalt tryck 250 bar (3600 psi)
Inloppsport G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
Utloppsport G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
Portstorlek G3/8, G1/2, M18×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT

The P40-OW Hydraulic Cut Off Solenoid Valve is a superior quality and exceptional value monoblock valve designed for a variety of demanding applications. It features a manual control method, 1 section, 1 spool, and a rated flow of 40 L/min (10.5 US gpm). This valve is capable of handling pressures up to 250 bar (3600 psi) and operates with a viscosity range of 15 - 75 mm²/s (15 cSt to 75 cSt). Its ambient temperature range is -40°C to +80°C (-40°F to +176°F), making it suitable for a wide range of operating environments. Designed for reliability and durability, this valve is ideal for use in material handling, construction, and agriculture. It is compatible with a range of equipment including telehandlers, forklifts, all-terrain cranes, stackers, aerial platforms, motor graders, midi-excavators, mini-excavators, skid steer loaders, and compact wheel loaders.
