P40-G12-2OT Hydraulic Valve System | Performance & Reliability

Kontrollmetod:Manuell

Spole:2 ventilsektioner

Nominellt flöde:40 l/min (10,5 US gpm)

Maximalt tryck:250 bar (3600 psi)

Inloppsport:G1/2

Utloppsport:G1/2

Portstorlek:G1/2

Märke:BXHS

Produkttyp:Monoblockriktningsventil

Produktserie:P40-serien Monoblockriktningsventil

Förpackningsstorlek:23*18*13

Bruttovikt:5.00 kg

Tillgänglighet: I lager

1177 Vyer letar efter den här produkten

P40-G12-2OT Hydraulic Valve System | Performance & Reliability

P40-G12-2OT Hydraulic Valve System | Performance & Reliability

P40-G12-2OT Hydraulic Valve System | Performance & Reliability drawing image

The P40-G12-2OT is a high-performance, reliable hydraulic pressure control valve designed for a wide range of applications, including construction, material handling, agriculture, and industrial vehicles. This 2-section, monoblock valve features a manual control method, rated flow of 40 L/min, and a maximum pressure of 250 bar.

P40-serien Monoblockriktningsventil Parametrar
Kontrollmetod Manuell, Pneumatisk, Elektropneumatisk, Elektrohydraulisk, Solenoid, Hydraulisk, Hydraulisk och Manuell, Kabel, Joystick, Solenoid och Joystick, Manuell och Joystick, Magnetventil och kabel
Spole 1 ventilsektion, 2 ventilsektioner, 3 ventilsektioner, 4 ventilsektioner, 5 ventilsektioner, 6 ventilsektioner, 7 ventilsektioner
Omgivningstemperaturintervall -40°C till +80°C (-40°F till +176°F)
Strukturtyp Monoblockventil
Sektion 1 sektion, 2 sektioner, 3 sektioner, 4 sektioner, 5 sektioner, 6 sektioner, 7 sektioner
Driftsviskositetsintervall 15 - 75 mm²/s (15 cSt till 75 cSt)
Nominellt flöde 40 l/min (10,5 US gpm)
Maximalt tryck 250 bar (3600 psi)
Inloppsport G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
Utloppsport G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
Portstorlek G3/8, G1/2, M18×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT

The P40-G12-2OT hydraulic pressure control valve is a robust and efficient solution for various mobile equipment. It offers a compact design with a 2-spool configuration, providing precise control over hydraulic systems. This monoblock valve is built for durability and reliability, operating within a wide viscosity range and temperature range. Its manual control method allows for simple and intuitive operation. With a rated flow of 40 L/min and a maximum pressure of 250 bar, this valve is suitable for a wide range of applications in construction, material handling, agriculture, and industrial vehicles. Some examples of its applications include telehandlers, forklifts, all-terrain cranes, stackers, aerial platforms, motor graders, midi-excavators, mini-excavators, skid steer loaders, and compact wheel loaders.
