What is the primary application of the P40-G12-G38-OT-QTW1 Directional Valve | Features, Specifications & Applications?

The P40-G12-G38-OT-QTW1 Directional Valve | Features, Specifications & Applications is designed for mobile hydraulic systems, agricultural machinery (such as tractors and harvesters), construction equipment (such as loaders and excavators), and industrial machinery. It ensures precise flow and directional control.

Is Boxinhuasheng a factory-direct manufacturer?

Yes, Boxinhuasheng (Qingzhou Boxinhuasheng Hydraulic Technology Co., Ltd.) is a factory-direct manufacturer established in 2001. We operate a 68,000m虏 facility with 4 modern manufacturing plants and 260+ production machines, supplying certified products directly to global customers.

What quality certifications do Boxinhuasheng products have?

All Boxinhuasheng directional control valves, gear pumps, and hydraulic accessories are CE certified, IATF 16949 compliant, and verified on-site by SGS, meeting international engineering standards.

Can Boxinhuasheng provide OEM/ODM customization services?

Yes, Boxinhuasheng has a team of 35 senior hydraulic engineers providing custom OEM manufacturing, ODM development, private labeling, and customized hydraulic system solutions tailored to specific operating pressures and flows.

What is the warranty and shipping lead time?

We offer a 1-year warranty with free replacement for any quality defects. Standard express delivery is within 30 days, supported by our robust annual capacity of 1.5 million hydraulic units and export experience to 80+ countries.

P40-G12-G38-OT-QTW1 Directional Valve | Features, Specifications & Applications

Name: P40-G12-G38-OT-QTW1 Directional Valve | Features, Specifications & Applications
Brand: Boxinhuasheng
SKU: BXHS-53621
Availability: InStock

Kontrollmetod:Manuell

Spole:2 ventilsektioner

Nominellt flöde:40 l/min (10,5 US gpm)

Maximalt tryck:250 bar (3600 psi)

Inloppsport:G1/2

Utloppsport:G1/2

Portstorlek:G3/8

Märke:BXHS

Produkttyp:Monoblockriktningsventil

Produktserie:P40-serien Monoblockriktningsventil

Förpackningsstorlek:23*18*13

Bruttovikt:6.00 kg

Tillgänglighet: I lager

Beskrivning

P40-G12-G38-OT-QTW1 Directional Valve | Features, Specifications & Applications

P40-G12-G38-OT-QTW1 Directional Valve | Features, Specifications & Applications drawing image

P40-G12-G38-OT-QTW1 Directional Valve is a hydraulic valve featuring manual control, 2 sections, and a monoblock structure. With a rated flow of 40 L/min, a maximum pressure of 250 bar, and a spool count of 2, it's designed for use in applications such as material handling, construction, agriculture, and industrial vehicles.

P40-serien Monoblockriktningsventil Parametrar
Kontrollmetod	Manuell, Pneumatisk, Elektropneumatisk, Elektrohydraulisk, Solenoid, Hydraulisk, Hydraulisk och Manuell, Kabel, Joystick, Solenoid och Joystick, Manuell och Joystick, Magnetventil och kabel
Spole	1 ventilsektion, 2 ventilsektioner, 3 ventilsektioner, 4 ventilsektioner, 5 ventilsektioner, 6 ventilsektioner, 7 ventilsektioner
Omgivningstemperaturintervall	-40°C till +80°C (-40°F till +176°F)
Strukturtyp	Monoblockventil
Sektion	1 sektion, 2 sektioner, 3 sektioner, 4 sektioner, 5 sektioner, 6 sektioner, 7 sektioner
Driftsviskositetsintervall	15 - 75 mm²/s (15 cSt till 75 cSt)
Nominellt flöde	40 l/min (10,5 US gpm)
Maximalt tryck	250 bar (3600 psi)
Inloppsport	G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
Utloppsport	G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
Portstorlek	G3/8, G1/2, M18×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT

**Key Features:**

* Manual Control
* 2 Section
* Monoblock Valve
* Rated Flow: 40 L/min (10.5 US gpm)
* Max Pressure: 250 bar (3600 psi)
* Operating Viscosity Range: 15 - 75 mm²/s (15 cSt to 75 cSt)
* Ambient Temperature Range: -40°C to +80°C (-40°F to +176°F)
* Spool: 2 Spool
* Series: P40 Series

**Application Areas:**

* Material Handling
* Construction and Earth Moving
* Agriculture
* Industrial Vehicles

**Applicable Models:**

* Telehandler
* Forklift
* All Terrain Crane
* Stacker
* Aerial Platform
* Motor Grader
* Midi-Excavator
* Mini-Excavator
* Skid Steer Loader
* Compact Wheel Loader
