P80-U116-U78-2OT Hydraulic Valve: Private Label & Bespoke Production

Kontrollmetod:Manuell

Spole:2 ventilsektioner

Nominellt flöde:80 l/min (21,2 US gpm)

Maximalt tryck:250 bar (3600 psi)

Inloppsport:SAE 10

Utloppsport:SAE 12

Portstorlek:SAE 10

Märke:BXHS

Produkttyp:Monoblockriktningsventil

Produktserie:P80-serien Monoblockriktningsventil

Förpackningsstorlek:26*18*11

Bruttovikt:8.00 kg

Tillgänglighet: I lager

971 Vyer letar efter den här produkten

P80-U116-U78-2OT Hydraulic Valve: Private Label & Bespoke Production

P80-U116-U78-2OT Hydraulic Valve: Private Label & Bespoke Production

P80-U116-U78-2OT Hydraulic Valve: Private Label & Bespoke Production drawing image

The P80 Series Pressure Reducing Valve is a high-performance hydraulic valve designed for use in a variety of applications, including construction equipment, material handling, agriculture, and industrial vehicles. It features a manual control, monoblock construction, and a rated flow of 80 L/min (21.2 US gpm). The valve is also available with private label and bespoke production options.

P80-serien Monoblockriktningsventil Parametrar
Kontrollmetod Manuell, Pneumatisk, Elektropneumatisk, Elektrohydraulisk, Solenoid, Hydraulisk, Hydraulisk och Manuell, Kabel, Joystick, Manuell och Joystick
Spole 1 ventilsektion, 2 ventilsektioner, 3 ventilsektioner, 4 ventilsektioner, 5 ventilsektioner, 6 ventilsektioner, 7 ventilsektioner
Omgivningstemperaturintervall -40°C till +80°C (-40°F till +176°F)
Strukturtyp Monoblockventil
Sektion 1 sektion, 2 sektioner, 3 sektioner, 4 sektioner, 5 sektioner, 6 sektioner, 7 sektioner
Driftsviskositetsintervall 15 - 75 mm²/s (15 cSt till 75 cSt)
Nominellt flöde 80 l/min (21,2 US gpm)
Maximalt tryck 315 bar (4600 psi)
Inloppsport G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT
Utloppsport G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT
Portstorlek G1/2, G3/4, M22×1.5, M27×2.0, SAE 10, 1/2 NPT, 3/4 NPT

The P80-U116-U78-2OT Hydraulic Valve is a pressure reducing valve designed for precise control of hydraulic pressure in a variety of applications. This manual control valve features a compact monoblock construction and a rated flow of 80 L/min (21.2 US gpm). It is designed to withstand a maximum pressure of 250 bar (3600 psi) and operates within a viscosity range of 15-75 mm²/s (15 cSt to 75 cSt). The valve is suitable for a wide range of ambient temperatures, from -40°C to +80°C (-40°F to +176°F). The P80 Series valve is ideal for use in construction equipment, material handling, agriculture, and industrial vehicles. Specifically, it is compatible with telehandlers, forklifts, all-terrain cranes, stackers, aerial platforms, motor graders, mini-excavators, skid steer loaders, and other similar machines. This valve offers private label and bespoke production options, allowing customization to meet specific requirements. This makes it an excellent choice for manufacturers seeking to differentiate their products and provide tailored solutions to their customers.
