SD8 Pneumatic Control Valve 2 Spool Sectional Type for Machinery

Kontrollmetod:Pneumatisk

Spole:2 ventilsektioner

Nominellt flöde:90 l/min (23,8 US gpm)

Maximalt tryck:315 bar (4600 psi)

Inloppsport:SAE 10

Utloppsport:SAE 10

Portstorlek:SAE 10

Märke:BXHS

Produkttyp:Sektionsstyrvventil

Produktserie:SD8-serien Sektionsstyrvventil

Förpackningsstorlek:34*24*15.5

Bruttovikt:12.50 kg

Tillgänglighet: I lager

98 Vyer letar efter den här produkten

SD8 Pneumatic Control Valve 2 Spool Sectional Type for Machinery

SD8 Pneumatic Control Valve 2 Spool Sectional Type for Machinery

SD8 Pneumatic Control Valve 2 Spool Sectional Type for Machinery drawing image

The SD8 Series Pneumatic Control Valve is a high-performance 2-spool sectional valve designed for heavy-duty machinery. With a rated flow of 80 L/min and a maximum pressure of 350 bar, it provides precise pneumatic control for applications in construction, agriculture, and material handling.

SD8-serien Sektionsstyrvventil Parametrar
Kontrollmetod Manuell, Pneumatisk, Elektropneumatisk, Elektrohydraulisk, Solenoid, Hydraulisk, Hydraulisk och Manuell, Kabel, Joystick, Solenoid och Joystick, Manuell och Joystick
Spole 1 ventilsektion, 2 ventilsektioner, 3 ventilsektioner, 4 ventilsektioner, 5 ventilsektioner, 6 ventilsektioner, 7 ventilsektioner, 8 ventilsektioner, 9 ventilsektioner, 10 ventilsektioner
Omgivningstemperaturintervall -40°C till +80°C (-40°F till +176°F)
Strukturtyp Sektionsventil
Sektion 1 sektion, 2 sektioner, 3 sektioner, 4 sektioner, 5 sektioner, 6 sektioner, 7 sektioner, 8 sektioner, 9 sektioner, 10 sektioner
Driftsviskositetsintervall 12 - 400 mm²/s (12 cSt till 400 cSt)
Nominellt flöde 90 l/min (23,8 US gpm)
Maximalt tryck 315 bar (4600 psi)
Inloppsport G1/2, G3/4, SAE 10
Utloppsport G1/2, G3/4, SAE 10, 3/4 NPT
Portstorlek G1/2, SAE 10

As a leading large-scale manufacturer of hydraulic products, we offer the SD8 Series Pneumatic Control Valve, a robust 2-spool sectional type solution engineered for global markets. This valve features a rated flow of 80 L/min (21.2 US gpm) and can withstand pressures up to 350 bar (5100 psi), ensuring reliable performance in demanding environments like construction sites and agricultural fields. It is widely compatible with forklifts, mini-excavators, skid steer loaders, and tractors. We provide comprehensive manufacturing services including OEM, ODM, and custom branding to meet specific technical requirements. Our factory offers direct wholesale supply with competitive pricing for bulk orders. We are actively seeking long-term partnerships with distributors, wholesalers, agents, and traders worldwide. Contact us for factory-direct sourcing and professional hydraulic solutions tailored to your machinery needs.
