Sectional Type SD8 Manual 4 Spool Directional Valve

Kontrollmetod:Manuell

Spole:4 ventilsektioner

Nominellt flöde:90 l/min (23,8 US gpm)

Maximalt tryck:315 bar (4600 psi)

Inloppsport:G1/2

Utloppsport:G3/4

Portstorlek:G1/2

Märke:BXHS

Produkttyp:Sektionsstyrvventil

Produktserie:SD8-serien Sektionsstyrvventil

Förpackningsstorlek:32*36*16

Bruttovikt:18.00 kg

Tillgänglighet: I lager

106 Vyer letar efter den här produkten

Sectional Type SD8 Manual 4 Spool Directional Valve

Sectional Type SD8 Manual 4 Spool Directional Valve

Sectional Type SD8 Manual 4 Spool Directional Valve drawing image

The SD8 Series 4-spool manual sectional directional valve is a high-performance hydraulic solution designed for flow rates up to 80 L/min and pressures up to 315 bar. This versatile valve offers precise manual control for a wide range of mobile and industrial applications, including construction, agriculture, and material handling equipment.

SD8-serien Sektionsstyrvventil Parametrar
Kontrollmetod Manuell, Pneumatisk, Elektropneumatisk, Elektrohydraulisk, Solenoid, Hydraulisk, Hydraulisk och Manuell, Kabel, Joystick, Solenoid och Joystick, Manuell och Joystick
Spole 1 ventilsektion, 2 ventilsektioner, 3 ventilsektioner, 4 ventilsektioner, 5 ventilsektioner, 6 ventilsektioner, 7 ventilsektioner, 8 ventilsektioner, 9 ventilsektioner, 10 ventilsektioner
Omgivningstemperaturintervall -40°C till +80°C (-40°F till +176°F)
Strukturtyp Sektionsventil
Sektion 1 sektion, 2 sektioner, 3 sektioner, 4 sektioner, 5 sektioner, 6 sektioner, 7 sektioner, 8 sektioner, 9 sektioner, 10 sektioner
Driftsviskositetsintervall 12 - 400 mm²/s (12 cSt till 400 cSt)
Nominellt flöde 90 l/min (23,8 US gpm)
Maximalt tryck 315 bar (4600 psi)
Inloppsport G1/2, G3/4, SAE 10
Utloppsport G1/2, G3/4, SAE 10, 3/4 NPT
Portstorlek G1/2, SAE 10

As a leading manufacturer of hydraulic solutions, we offer the SD8 Series Sectional Type Manual 4 Spool Directional Valve, engineered for demanding environments. This valve features a rated flow of 80 L/min (21.2 US gpm) and a maximum pressure rating of 315 bar (4600 psi), making it ideal for machinery such as forklifts, skid steer loaders, mini-excavators, and tractors. The sectional design provides flexible configuration, while G1/2 inlet and G3/4 outlet ports ensure standard connectivity. We specialize in factory-direct supply, providing extensive OEM, ODM, and custom branding (Private Label) services to meet specific technical requirements. Our facility is equipped for large-scale production, supporting wholesale orders with competitive pricing. We are actively seeking global partners, including distributors, wholesalers, agents, and traders, to expand our market reach. Whether you need a reliable supplier for forestry wood splitters or complex aerial platforms, our factory provides the expertise and manufacturing capacity to support your business growth.
