Solenoid Hydraulic Valve | SD5 Model | Factory Direct & Customizable

Kontrollmetod:Solenoid

Spole:1 ventilsektion

Nominellt flöde:45 l/min (11,8 US gpm)

Maximalt tryck:315 bar (4600 psi)

Inloppsport:G3/8

Utloppsport:G3/8

Portstorlek:G3/8

Märke:BXHS

Produkttyp:Monoblockriktningsventil

Produktserie:SD5-serien Monoblockriktningsventil

Förpackningsstorlek:30*13*13

Bruttovikt:5.40 kg

Tillgänglighet: I lager

1138 Vyer letar efter den här produkten

Solenoid Hydraulic Valve | SD5 Model | Factory Direct & Customizable

Solenoid Hydraulic Valve | SD5 Model | Factory Direct & Customizable

Solenoid Hydraulic Valve | SD5 Model | Factory Direct & Customizable drawing image

The SD5 Series Log Splitter Spool Valve Solenoid Hydraulic Valve is a durable and reliable valve designed for use in a variety of applications, including material handling, construction, agriculture, and industrial vehicles. This monoblock valve features a solenoid control method, 1 section, 40 L/min rated flow, and 305 bar maximum pressure. It's available directly from the factory and can be customized to meet your specific needs.

SD5-serien Monoblockriktningsventil Parametrar
Kontrollmetod Manuell, Pneumatisk, Elektropneumatisk, Elektrohydraulisk, Solenoid, Hydraulisk, Hydraulisk och Manuell, Kabel, Joystick
Spole 1 ventilsektion, 2 ventilsektioner, 3 ventilsektioner, 4 ventilsektioner, 5 ventilsektioner, 6 ventilsektioner, 7 ventilsektioner
Omgivningstemperaturintervall -40°C till +60°C (-40°F till +140°F)
Strukturtyp Monoblockventil
Sektion 1 sektion, 2 sektioner, 3 sektioner, 4 sektioner, 5 sektioner, 6 sektioner, 7 sektioner
Driftsviskositetsintervall 15 - 75 mm²/s (15 cSt till 75 cSt)
Nominellt flöde 40 l/min (10,5 US gpm)
Maximalt tryck 305 bar (4400 psi)
Inloppsport G3/8, G1/2, M18×1.5, M20×1.5, SAE 6, SAE 8, G1-1/2
Utloppsport G3/8, G1/2, M18×1.5, M20×1.5, SAE 6, SAE 8
Portstorlek G3/8, G1/2, M18×1.5, M20×1.5, SAE 6, SAE 8

The SD5 Series Log Splitter Spool Valve Solenoid Hydraulic Valve is a high-performance, heavy-duty valve designed for use in demanding applications. It features a compact design, robust construction, and reliable performance. This monoblock valve is controlled by a solenoid, offering precise and responsive operation. The valve is available in a variety of configurations to meet your specific needs. It is also available with a range of options and accessories, including custom-engineered solutions. The SD5 Series is the perfect choice for a wide range of applications including material handling, construction, agriculture, and industrial vehicles. It is also suitable for use in a variety of harsh environments. Contact us today to learn more about this high-quality hydraulic valve.
