Source ZT20 Directional Control Valves from a Trusted Manufacturer

Kontrollmetod:Manuell

Spole:2 ventilsektioner

Nominellt flöde:90 l/min (23,8 US gpm)

Maximalt tryck:250 bar (3600 psi)

Inloppsport:G3/4

Utloppsport:G3/4

Portstorlek:G3/4

Märke:BXHS

Produkttyp:Hydraulisk styrventil

Produktserie:ZT20-serien Hydraulisk styrventil

Förpackningsstorlek:23*18*11

Bruttovikt:7.91 kg

Tillgänglighet: I lager

1150 Vyer letar efter den här produkten

Source ZT20 Directional Control Valves from a Trusted Manufacturer

Source ZT20 Directional Control Valves from a Trusted Manufacturer

Source ZT20 Directional Control Valves from a Trusted Manufacturer drawing image

The ZT20 Series Directional Control Valve is a high-performance, 2-section monoblock valve designed for a variety of applications in material handling, construction, agriculture, and industrial vehicles. It features manual control, 100 L/min rated flow, and 250 bar maximum pressure.

ZT20-serien Hydraulisk styrventil Parametrar
Kontrollmetod Manuell, Kabel, Joystick, Manuell och Joystick
Spole 1 ventilsektion, 2 ventilsektioner, 3 ventilsektioner, 4 ventilsektioner, 5 ventilsektioner, 6 ventilsektioner
Nominellt flöde 100 l/min (26,5 US gpm)
Maximalt tryck 250 bar (3600 psi)
Inloppsport G1/2, G3/4, M22×1.5, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT
Utloppsport G1/2, G3/4, M22×1.5, M27×2.0, SAE 8, SAE 10, 1/2 NPT, 3/4 NPT
Portstorlek G1/2, G3/4, M22×1.5, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT
Sektion 1 sektion, 2 sektioner, 3 sektioner, 4 sektioner, 5 sektioner, 6 sektioner
Strukturtyp Monoblockventil
Omgivningstemperaturintervall -40°C till +80°C (-40°F till +176°F)
Driftsviskositetsintervall 15 - 75 mm²/s (15 cSt till 75 cSt)

This ZT20 Series Directional Control Valve is a reliable and durable solution for your hydraulic system needs. It features a compact, monoblock design with a 2-section configuration, offering precise control and efficient operation. With a rated flow of 100 L/min and a maximum pressure of 250 bar, this valve is suitable for a wide range of applications. Its manual control allows for easy operation and adjustment. The valve is designed for use in various industries, including material handling, construction, earthmoving, agriculture, and industrial vehicles. It is particularly well-suited for use in telehandlers, forklifts, all-terrain cranes, stackers, aerial platforms, motor graders, midi-excavators, mini-excavators, skid steer loaders, and compact wheel loaders. With a robust construction and high-quality materials, this ZT20 Series valve delivers long-lasting performance and reliability.
